Multimeter Sonel CMM-30
SKU: SL-CMM-30-EU-R1
Free shipping over 200 EUR
Estimated shipping time 3-4 weeks
Estimated shipping time 3-4 weeks
| Product information | |
|---|---|
| Product name | Multimeter Sonel CMM-30 |
| Brand | Sonel |
| DC voltage | |
| Measurement range | up to 1000 V |
| Resolution | from 0,1 mV |
| Accuracy ±(% m.v. + digits) | from ±(0.5 % m.v. + 8 digits) |
| AC voltage | |
| Measurement range | up to 1000 V |
| Resolution | from 0,001 V |
| Accuracy ±(% m.v. + digits) | from ±(1.0 % m.v. + 5 digits) |
| DC current | |
| Measurement range | up to 10 A |
| Resolution | from 0,1 μA |
| Accuracy ±(% m.v. + digits) | from ±(1.0 % m.v. + 3 digits) |
| AC current (TRMS) | |
| Measurement range | up to 10 A |
| Resolution | from 0,1 μA |
| Accuracy ±(% m.v. + digits) | from ±( 1.0% m.v. + 3 digits) |
| Resistance | |
| Measurement range | up to 60 MΩ |
| Resolution | from 0,1 Ω |
| Accuracy ±(% m.v. + digits) | from ±(1.5 % m.v. + 5 digits) |
| Low Z (AC / DC voltage) | |
| Measurement range | up to 1000 V |
| Resolution | from 0,001 V |
| Accuracy ±(% m.v. + digits) | from ±(3.0 % m.v. + 5 digits) |
| Capacity | |
| Measurement range | up to 6000 µF |
| Resolution | from 0,01 nF |
| Accuracy ±(% m.v. + digits) | from ±(3.0 % m.v. + 5 digits) |
| Frequency | |
| Measurement range | up to 9,999 kHz |
| Resolution | from 0,001 Hz |
| Accuracy ±(% m.v. + digits) | ±(1.0 % m.v. + 5 digits) |
| Duty cycle | |
| Measurement range | 20 - 80 % |
| Resolution | 0,1% |
| Accuracy ±(% m.v. + digits) | ±(1.2 % m.v. + 2 digits) |
| Temperature measurement (°C) | |
| Measurement range | -20 - +760 °C |
| Resolution | 0,1 °C |
| Accuracy ±(% m.v. + digits) | ±(1.0 % m.v. + 5 °C) |
| Temperature measurement (°F) | |
| Measurement range | -4 - +1400 °F |
| Resolution | 0,1 °F |
| Accuracy ±(% m.v. + digits) | ±(1.0 % m.v. + 9 °F) |
| Features | |
| Counting | 6 000 digits |
| Automatic range selection | Yes |
| Manual range selection | Yes |
| The HOLD function | Yes |
| Relative measurement | Yes |
| MAX / MIN measurement | Yes |
| AVG measurement | Yes |
| Beeper | Yes |
| Continuity | Yes |
| Diode test | Yes |
| TRMS measurement | Yes |
| AC + DC measurement | Yes |
| Peak HOLD function | Yes |
| Easy access to A / mA fuses | Yes / Yes |
| Battery indicator | Yes |
| Automatic shutdown function | Yes |
| Integrated flashlight | Yes |
| Environmental Conditions | |
| Measuring category acc. to EN 61010 | CAT IV 600 V / CAT III 1000 V |
| Ingress protection | IP67 |
| Operating temperature | +0 – +40°C | 32 – 104°F |
| Storage temperature | -20 – +60°C | -4 – 140°F |
| Humidity | up to 80 % at 31°C, with linear slope to 50 % at 40°C |
| Internal impedance | >10 MΩ (V DC) / >9 MΩ (V AC) |
| Data Storage | |
| Memory | In mobile application |
| Computer Interface | |
| Type of display | segment-based LCD, 4 digits |
| Display backlight | automatic and manual |
| Dimensions and Weight | |
| Dimensions (W x H x D) | 75 x 170 x 48 mm (3,0 x 6,7 x 1,9 in) |
| Weight | - |
- Temperature probe type K adapter
- Alkaline battery AAA LR03 (24A) 1.5 V (4pcs)
- Factory calibration certificate
- S-7 Standard carrying case
- Test leads set for CMM (CAT IV, M)
- Type K temperature probe
