Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-2.88

SKU: GW-PSW800-2.88-EU-R1

Switching D.C. Power Supply

  • Features
  • Voltage Rating: 800V, Output Power Rating: 720W
  • Constant Power Output for Multiple Range (V&I) Operation
  • CV/CC Priority; Particularly Suitable for the Battery and LED Industry
  • 1/3 Rack Mount Size Design (EIA/JIS Standard) for 720W
Free shipping over 200 EUR
Estimated shipping time 4-5 weeks

Why buy the Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-2.88

Are you in need of a versatile and efficient power supply for your projects? Look no further than the GW Instek PSW800-2.88. This multi-range programmable switching DC power supply offers a wide range of voltage and output power options, with fifteen different models available. The PSW-Series has a maximum output power of 720W and a voltage rating of 800V, making it suitable for a variety of applications.

What are key features Power Supply GW Instek PSW800-2.88?

One of the key features of the PSW800-2.88 is its flexibility in power utilization. The multi-range feature allows for the efficient configuration of voltage and current within the rated power range. Additionally, the PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, providing a broad coverage of applications and reducing the cost for multiple power supply products.

The GW Instek PSW800-2.88 prioritizes DUT protection

The PSW800-2.88 also prioritizes DUT protection with its C.V/C.C priority selection. This feature limits the inrush current that can damage capacitive and current-intensive loads. Additionally, the adjustable slew rate allows for smooth and slow voltage transitions during power On-Off, reducing spike current and protecting current-intensive devices.

What Power Supply GW Instek PSW800-2.88 include?

The PSW800-2.88 also includes OVP and OCP protection, with default levels set at 110% of the rated voltage/current of the power supply. When either protection level is tripped, the power output will be switched off to protect the DUT. The power supply also includes USB Host/Device and LAN interfaces as standard, with GPIB-USB adapter and RS232-USB cable available as optional. The LabView driver and Data Logging PC software are supported on all available interfaces, with an analog control/monitoring connector also available on the rear panel for external control and monitoring.

The Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-2.88 offers versatility, efficiency, and protection for your projects, making it an excellent choice for your power supply needs.

Product information
Product name Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-2.88
Brand GW Instek
Dimensions and Weight
Dimensions (W x H x D) -
Weight -
  • GTL-240 - USB Cable, USB 2.0, A-B Type (L Type), 1200mm
  • CD (User manual, Programming manual)
  • Power cord
  • PSW-008 - Basic Accessory Kit for 250V/800V models
  • PSW-011 - Output terminal cover for 250V/800V models
  • PSW-012 - High voltage output terminal for 250V/800V model
  • PSW800-2.88 - 720W Multi-Range Programmable Switching D.C. Power Supply
