Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-1.44

SKU: GW-PSW800-1.44-EU-R1

Programmable Switching D.C. Power Supply Features:

  • Voltage Rating: 800V, Output Power Rating: 360W
  • Constant Power Output for Multiple Range (V&I) Operation
  • CV/CC Priority; Particularly Suitable for the Battery and LED Industry
  • 1/2 Rack Mount Size Design (EIA/JIS Standard) for 360W
Free shipping over 200 EUR
Estimated shipping time 4-5 weeks

The Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-1.44 is the perfect solution for a wide range of applications. With a voltage rating of 800V and an output power rating of 360W, this power supply offers constant power output for multiple range (V&I) operation. The PSW-Series is particularly suitable for the battery and LED industry, thanks to its CV/CC priority selection feature. This feature is a very useful feature for DUT protection, as the conventional power supply normally operates under C.V mode when the power output is turned on. This could bring a high inrush current to the capacitive load or current-intensive load at the power output-on stage. Taking the I-V curve verification of LED as an example, it becomes a very challenging task to perform this measurement using a conventional power supply. With LED connected to a power supply under C.V mode as the initial setting, when the power output is turned on and the voltage rises to the LED forward voltage, the current will suddenly peak up and exceed the preset value of current limit. Upon detecting this high current, the power supply starts the transition from C.V mode to C.C mode. Though the current becomes stable after the C.C mode being activated, the current spike occurred at the C.V and C.C crossover point may possibly damage the DUT. At the power output-on stage, the PSW-Series is able to operate under C.C priority to limit the current spike occurred at the threshold voltage and therefore protects DUT from the inrush current damage.

The adjustable slew rate of the PSW-Series allows users to set for either output voltage or output current, a specific rise time from low to high level transition, and a specific fall time from high to low level transition. This facilitates the characteristic verification of a DUT during voltage or current level changes with controllable slew rates. Most manufacturing tests of lighting device or large capacitor during power output-on are associated with the occurrence of high surge current, which can greatly reduce the life time of the DUT. To prevent inrush current from damaging current-intensive devices, a smooth and slow voltage transition during power On-Off can significantly reduce the spike current and protect the device from high current damage.

The OVP and OCP are provided with the PSW-Series. Both OVP and OCP levels can be selected, with default level set at 110%, of the rated voltage/current of the power supply. When any of the protection levels is tripped, the power output will be switched off to protect the DUT. The PSW-Series provides USB Host/Device and LAN interfaces as standard, GPIB-USB adapter and RS232-USB cable as optional. The LabView driver and the Data Logging PC software are supported on all the available interfaces. An analog control/monitoring connector is also available on the rear panel for external control of power On/Off and external monitoring of power output Voltage and Current.

The PSW-Series can be connected in series for maximum 2 units or in parallel for maximum 3 units, the capability of connecting multiple PSW-Series units for higher voltage or higher current output provides a broad coverage of applications. With the flexibility of multi-range power utilization and series/parallel connection, the PSW-Series significantly reduces the users’ cost for various power supply products to accommodate the projects with different power requirements.

Product information
Product name Multi-Range Programmable Switching D.C. Power Supply GW Instek PSW800-1.44
Brand GW Instek
Dimensions and Weight
Dimensions (W x H x D) -
Weight -
  • GTL-240 - USB Cable, USB 2.0, A-B Type (L Type), 1200mm
  • CD (User manual, Programming manual)
  • Power cord
  • PSW-008 - Basic Accessory Kit for 250V/800V models
  • PSW-011 - Output terminal cover for 250V/800V models
  • PSW-012 - High voltage output terminal for 250V/800V model
  • PSW800-1.44 - 360W Multi-Range Programmable Switching D.C. Power Supply
