Mixed-Signal Oscilloscope GW Instek MSO-2202EA

SKU: GW-MSO-2202EA-EU-R1

The MSO-2000 series is a mixed-signal oscilloscope, which offers dual analog channels + 16 digital channels or 4 analog channels + 16 digital channels.

    Free shipping over 200 EUR
    Estimated shipping time 4-5 weeks

    The GW Instek MSO-2202EA is a top-of-the-line mixed-signal oscilloscope that offers a unique combination of dual analog channels and 16 digital channels. This powerful oscilloscope is part of the MSO-2000 series and is designed to provide electronic engineers and technicians with advanced features and capabilities to troubleshoot and debug mixed-signal electronic systems with ease.

    Dual analog channels that allow for a high level of flexibility and versatility with GW Instek MSO-2022EA

    One of the standout features of the MSO-2202EA is its dual analog channels that allow for a high level of flexibility and versatility. With a maximum input frequency of 1GHz and a high input impedance of 1MΩ, the oscilloscope can measure a wide range of signals. The high sample rate of up to 2GSa/s ensures minimal distortion in captured and displayed waveforms.

    The MSO-2202EA also offers 16 digital channels that make it even more versatile. These digital channels can capture and display digital signals such as I2C, SPI, UART, and more. With a high sample rate of up to 100MSa/s, the digital channels provide detailed waveform captures with minimal distortion.

    GW Instek MSO-2022EA have advanced measurement functions

    Advanced measurement functions like frequency counter, period, pulse width, and more, provide easy and precise measurements on various types of signals. Additionally, the oscilloscope offers advanced analysis capabilities such as FFT analysis, which allows for the analysis of frequency components of a signal. The mask testing function also allows you to define pass/fail criteria for your signal and make measurements automatically.

    A high-resolution color display with advanced triggering capabilities allows for easy identification and analysis of complex signals. The oscilloscope also offers a wide range of connectivity options including USB, LAN, and GPIB, allowing for data storage, analysis, and remote control. A built-in 25 MHz function/arbitrary waveform generator also enables the generation of various types of signals for testing and troubleshooting.

    Overall, the GW Instek MSO-2202EA mixed-signal oscilloscope is the perfect tool for electronic engineers and technicians looking for a powerful and versatile instrument. With dual analog channels and 16 digital channels, advanced measurement and analysis functions, and a variety of connectivity options, this oscilloscope can easily troubleshoot and debug mixed-signal electronic systems. It is an excellent investment for those looking for a high-performing, reliable oscilloscope for their electronic testing needs.

    Product information
    Product name Mixed-Signal Oscilloscope GW Instek MSO-2202EA
    Brand GW Instek
    Dimensions and Weight
    Dimensions (W x H x D) 208 x 384 x 127.3 mm (8,2 x 15,1 x 5,0 in)
    Weight 2.8 kg (6,2 lbs)
    • GTL-16E - 16-Channel Logic Analyzer Probe
    • GTP-200B-4 - Oscilloscope Probe, 200MHz (10:1/1:1) Switching Passive Probe, BNC(P/M)
    • CD (User manual)
    • Power cord
    • GW Instek MSO-2202EA device
