DV Power
The Three-Phase Winding Ohmmeter DV Power TWA25A
TWA25A-EU-R1

The TWA25A device is specifically designed for measuring the resistance of both inductive and non-inductive loads. It is built to comply with the safety standard IEC 61010-1, ensuring safe operation during testing procedures. Furthermore, it fulfills the requirements set forth by IEC 60076, which specifies the standards for power transformers.

  • Test current 5 mA – 25 A
  • Open voltage up to 55 V
  • Measuring range 0,1 µΩ – 10 kΩ
  • Typical accuracy ± (0,1 % rdg + 0,1 % FS)
